To solve the problem of ball valve leakage, corresponding measures should be taken according to the specific reasons. Here are some common ball valve leakage causes and solutions:
First, common leakage causes
1. Seal damage: the sealing surface or sealing gasket is worn or aged due to long-term use or medium corrosion.
2. Spool or seat mismatch: the fit between spool and seat is not tight, and there is a gap.
3. The valve stem seal is not strict: the seal between the valve stem and the valve body fails, resulting in medium leakage.
4. Improper selection of valve material: valve material does not adapt to the medium environment, resulting in corrosion or wear.
5. Improper installation: The valve is not installed in accordance with the specifications, such as the installation position is not correct, and the fastening bolts are not tightened.
6. Improper operation: excessive force or improper operation during use leads to valve damage.
Second, solutions
1. Check and replace seals:
- First check whether the sealing surface and sealing gasket are worn or aged.
- If damage is found, new seals should be replaced in time.
- Pay attention to the selection of sealing materials that match the medium environment.
2. Adjust the match between the spool and the seat:
- Check the fit between the spool and the seat.
- If the clearance is too large, try to adjust the spool position or replace the spool and seat with a new one.
3. Strengthen valve stem seal:
- Check the seal between stem and valve body.
- If the seal fails, a new seal can be replaced or other sealing methods can be used.
4. Replace the appropriate valve material:
- Select the appropriate valve material according to the medium environment.
- If the original valve material is not suitable for the medium environment, a new valve should be considered.
5. Reinstall the valve:
- If leakage caused by improper installation is found, the valve should be re-installed.
- Ensure that the installation position is correct, the fastening bolts are tightened and evenly stressed.
6. Standard operation:
- Train operators to ensure they understand the proper operation of ball valves.
- Avoid valve damage caused by excessive force or improper operation during use.
7. Other measures:
- For leaks caused by impurities in the medium, the inside of the valve can be cleaned regularly.
- For leaks due to high or low temperatures, insulation or cooling measures may be applied.
- In case of emergency, temporary sealing materials such as gaskets or mud can be used for sealing, but fundamental repair measures should be taken as soon as possible.
Third, summary
To solve the problem of ball valve leakage, it is necessary to take targeted measures according to specific reasons. Ball valve leakage can be effectively solved by checking the seal, adjusting the fit of the spool and the seat, strengthening the stem seal, replacing the appropriate material, reinstalling the valve and standardizing the operation. At the same time, regular maintenance and maintenance of the valve is also one of the important measures to prevent leakage.
